for light control of JOS Technik 12V flap actuators and for 12V lighting systems!
Attention: Only suitable for 12 V DC !!!
This 12 V DC LED lamp as a light bar with bracket can be dimmed without flickering with light controls from JOS Technik. Up to 5 dimmable 6W light strips can be connected directly without a relay module.
If LED components are operated directly with a perfectly smoothed DC voltage (DC voltage without significant ripple noise), these LED lamps also show a flicker value that is negligible in practice and are therefore considered flicker-free.
Technical dataSupply voltage 12 V DC
Energy efficiency category A+
Socket strip light with mounting clips
Power consumption 6 W
Light flux 540-600 lm
Lumen per Watt ≥ 90-100 lm / W
Beam angle 120°
Colour temperature 3000 - 3200 Kelvin - warm white
Colour rendering index > 80 RA
Average light bulb lifespan 50.000 hours
Average amount of switching cycles > 10.000
Dimensions (L x W x H) 380mm x 18mm x 12mm
Ignition time >0,36 s
Intensity at the end of lifespan 10 %
Temperature range -20°C - +40°C
Weighted power consumption 6,0 kWh / 1000 h
Luminous efficiency ≥ 90%
Seconds until 60% of full light flux is reached 0,58 s
Protection class IP 65
Mercury content 0,0 mg
Max. light intensity (candela) 600 cd
Lamps labelled with the WEEE symbol can be returned to suitable collection centres.
